Pneumatic cylindrical screen printer

( HJ-250AB ) Pneumatic cylindrical screen printer Parameter max printing area: 230×130mm max frame size: 430×280mm Max.workpiece length: <280mm Taper range: positive≤15° negative≤7° Max diameterwhole circle: ø72mm, arc circle: ø230mm Max. printing speed: 1000pcs/hr Wattage: 220V/50HZ 50W Air consumption: 56L/min Dimension: 640×760×125mm Features: 1.Micro-processor control each function with high automation and easy operation 2.4-digit auto counter built in 3.Which have multifunction, can print onto cylindrical, conical and flat surface 4.Auto ink squeegeeing and flooding, worktable elevating to assure easy operation and consistent print quality; 5.Printing stroke and speed are adjustable to meet different requirements 6.Auto balanced squeegee to ensure equalized printing pressure 7.Fine adjusted available on worktable up/down and plane angle, and frame front/rear, left/right and up/down with high printing precision. 8.Squeegee can be lifted independently so that screen replacing is easy and convenient
